Sany EV490-20 Prime Mover
4x2 electric prime mover — 350 kWh battery, 360 kW peak motor and 2,800 Nm peak torque, rated to 80-tonne gross combination weight for container and heavy haulage.
Complete data sheet.
Click any group to expand. All figures from manufacturer's specification; subject to homologation for Singapore LTA Vehicle Type Approval.
| Battery | 350 kWh / 608 Ah |
|---|---|
| Electric motor | TZ388XSLGE03 |
| Power (nominal / peak) | 250 / 360 kW (335 / 482 hp) |
| Torque (nominal / peak) | 1,228 / 2,800 Nm |
| Motor controller | KTZ61X85SSLA01 |
| Transmission | 6-speed automated manual (AMT) |
| Gear shift | Column-mounted shifter |
| Wheelbase | 4,000 mm |
|---|---|
| Overall length | 6,465 mm |
| Overall width | 2,545 mm |
| Overall height | 3,715 mm |
| Front overhang | 1,515 mm |
| Rear overhang | 950 mm |
| Fifth wheel height | 1,300 mm |
| Turning circle (kerb to kerb) | 13,300 mm |
| Unladen — 1st axle | 6,200 kg |
|---|---|
| Unladen — 2nd axle | 3,500 kg |
| Unladen total | 9,700 kg |
| Gross combination weight | 80,000 kg |
| Drive configuration | 4x2 |
Cover that matches the duty cycle.
5 years / 500,000 km
Battery warranty.
3 years / 250,000 km
Motor warranty.
1 year, unlimited
Vehicle warranty.
Sany EV490-20 Prime Mover — frequently asked questions.
What battery does the Sany EV490-20 Prime Mover have?
The Sany EV490-20 Prime Mover uses a 350 kWh / 608 Ah battery pack.
What is the payload capacity of the Sany EV490-20 Prime Mover?
The Sany EV490-20 Prime Mover has a gross vehicle weight of 80,000 kg.
What warranty is offered on the Sany EV490-20 Prime Mover?
Manufacturer warranty on the Sany EV490-20 Prime Mover: Battery — 5 years / 500,000 km; Motor — 3 years / 250,000 km; Vehicle — 1 year, unlimited. Terms are set by the manufacturer and should be confirmed in writing before purchase.
Is the Sany EV490-20 Prime Mover available in Singapore?
The Sany EV490-20 Prime Mover is listed on EVhubs as available to Singapore fleet operators. EVhubs is a supplier-neutral listing platform — we publish specifications, not prices. Contact us for a quotation sized to your route and duty cycle.
